base class for all function block elements in a data flow More...
#include <EVCStateMachine.h>
Inherited by oETCS::DF::CAnd, oETCS::DF::CBoolGate, oETCS::DF::CBoolSwitch, oETCS::DF::CBrakingToTargetSpeed, oETCS::DF::CCeelingSpeedControl, oETCS::DF::CComBlockIn, oETCS::DF::CComBlockOut, oETCS::DF::CCondition, oETCS::DF::CControlFlow, oETCS::DF::CDivision, oETCS::DF::CDMIInput, oETCS::DF::CDMIOutput, oETCS::DF::CDoubleArrayAccessor, oETCS::DF::CDoubleEqual, oETCS::DF::CDoubleEqualOrGreater, oETCS::DF::CDoubleGate, oETCS::DF::CDoubleGreater, oETCS::DF::CDoubleSwitch, oETCS::DF::CEmergencyBrake, oETCS::DF::CEnteredTrigger, oETCS::DF::CEVCCondition, oETCS::DF::CIntEqual, oETCS::DF::CIntGreater, oETCS::DF::CLevelCondition, oETCS::DF::CMultiplication, oETCS::DF::CNot, oETCS::DF::COdometer, oETCS::DF::COr, oETCS::DF::CServiceBrake, oETCS::DF::CStorage, oETCS::DF::CStringEqual, oETCS::DF::CStringGate, oETCS::DF::CStringSwitch, oETCS::DF::CSubstraction, oETCS::DF::CSum, and oETCS::DF::CXor.
Classes | |
| class | CInput |
| container template class for input value storages of the type VALUE_T More... | |
Public Member Functions | |
| virtual void | Calculate ()=0 throw (::oETCS::DF::Error::CException) |
| virtual method for computing all outputs and setting the all referenced outputs | |
| CFunctionBlock (oETCS::DF::CEVCStateMachine *const pStateMachine) throw () | |
| general constructor | |
| CFunctionBlock (const CFunctionBlock &Source) | |
| deleted copy constructor to avoid copying | |
| virtual | ~CFunctionBlock () throw () |
| destructor | |
Public Attributes | |
| oETCS::DF::CEVCStateMachine *const | m_pStateMachine |
| pointer to the all contenting EVC state machine | |
Private Member Functions | |
| CFunctionBlock & | operator= (CFunctionBlock &Source) throw () |
| private assignment operator to avoid assignment | |
Detailed Description
base class for all function block elements in a data flow
Definition at line 743 of file EVCStateMachine.h.
Constructor & Destructor Documentation
| oETCS::DF::CFunctionBlock::CFunctionBlock | ( | oETCS::DF::CEVCStateMachine *const | pStateMachine | ) | throw () |
general constructor
- Parameters
-
[in] pStateMachine pointer to the contenting state machine
Definition at line 1320 of file EVCStateMachine.cpp.
| oETCS::DF::CFunctionBlock::CFunctionBlock | ( | const CFunctionBlock & | Source | ) |
deleted copy constructor to avoid copying
|
virtual |
destructor
Definition at line 1338 of file EVCStateMachine.cpp.
Member Function Documentation
|
pure virtual |
virtual method for computing all outputs and setting the all referenced outputs
- Remarks
- must be implemented by any inheriting class
Implemented in oETCS::DF::CDMIOutput, oETCS::DF::CDMIInput, oETCS::DF::CComBlockOut, oETCS::DF::CComBlockIn, oETCS::DF::CIntEqual, oETCS::DF::CEVCCondition, oETCS::DF::CStringSwitch, oETCS::DF::CLevelCondition, oETCS::DF::CEnteredTrigger, oETCS::DF::CCeelingSpeedControl, oETCS::DF::CBrakingToTargetSpeed, oETCS::DF::CStringGate, oETCS::DF::CDoubleSwitch, oETCS::DF::CDoubleGate, oETCS::DF::CBoolSwitch, oETCS::DF::CBoolGate, oETCS::DF::CStringEqual, oETCS::DF::CIntGreater, oETCS::DF::CDoubleGreater, oETCS::DF::CDoubleEqualOrGreater, oETCS::DF::CDoubleArrayAccessor, oETCS::DF::CXor, oETCS::DF::CServiceBrake, oETCS::DF::CSum, oETCS::DF::COdometer, oETCS::DF::CSubstraction, oETCS::DF::CNot, oETCS::DF::CEmergencyBrake, oETCS::DF::CMultiplication, oETCS::DF::CDoubleEqual, oETCS::DF::CControlFlow, oETCS::DF::CDivision, oETCS::DF::COr, oETCS::DF::CStorage, oETCS::DF::CAnd, and oETCS::DF::CCondition.
|
private |
private assignment operator to avoid assignment
Definition at line 1349 of file EVCStateMachine.cpp.
Member Data Documentation
| oETCS::DF::CEVCStateMachine* const oETCS::DF::CFunctionBlock::m_pStateMachine |
pointer to the all contenting EVC state machine
Definition at line 894 of file EVCStateMachine.h.
Referenced by oETCS::DF::CCondition::Calculate(), and oETCS::DF::CDMIOutput::Calculate().
The documentation for this class was generated from the following files:
