class for outputs to the driver via the DMI More...
#include <FunctionBlocks.h>
Public Member Functions | |
| virtual void | Calculate () throw (::oETCS::DF::Error::CException) |
| pure virtual method for computing all outputs | |
| CDMIOutput (oETCS::DF::CEVCStateMachine *const pStateMachine, const oETCS::DF::DATA_T &eType, const ::std::string &Label="", const bool &bInitialVisible=true) throw () | |
| general constructor | |
| virtual | ~CDMIOutput () throw () |
| destructor | |
Public Attributes | |
| oETCS::DF::BOOL_INPUT_T | m_bBoolMessage |
| storage of a boolean message | |
| oETCS::DF::BOOL_INPUT_T | m_bVisible |
| storage of the visible flag input | |
| oETCS::DF::DOUBLE_INPUT_T | m_dDoubleMessage |
| storage of a double message | |
| oETCS::DF::DOUBLE_ARRAY_INPUT_T | m_DoubleArrayMessage |
| storage of a double array message | |
| const oETCS::DF::DATA_T | m_eType |
| data type of input | |
| oETCS::DF::INT_INPUT_T | m_iIntMessage |
| storage of an integer message | |
| const ::std::string | m_Label |
| optional label | |
| oETCS::DF::CEVCStateMachine *const | m_pStateMachine |
| pointer to the all contenting EVC state machine | |
| oETCS::DF::STRING_INPUT_T | m_StringMessage |
| storage of a string message | |
Detailed Description
class for outputs to the driver via the DMI
Definition at line 1784 of file FunctionBlocks.h.
Constructor & Destructor Documentation
|
explicit |
general constructor
- Parameters
-
[in] pStateMachine pointer to the parent EVC state machine object [in] eType data type of the DMI input object [in] Label optional label string [in] bInitialVisible optional flag for initial visibility
Definition at line 1752 of file FunctionBlocks.cpp.
|
virtual |
destructor
Definition at line 1772 of file FunctionBlocks.cpp.
Member Function Documentation
|
virtual |
pure virtual method for computing all outputs
- Remarks
- must me implemented by any inheriting class
Implements oETCS::DF::CFunctionBlock.
Definition at line 1783 of file FunctionBlocks.cpp.
References oETCS::DF::BOOL, oETCS::DF::DOUBLE, oETCS::DF::DOUBLE_ARRAY, oETCS::DF::INT, oETCS::DF::CFunctionBlock::CInput< INPUT_TYPE_T >::IsModified(), m_bBoolMessage, m_dDoubleMessage, m_DoubleArrayMessage, m_eType, m_iIntMessage, oETCS::DF::CFunctionBlock::m_pStateMachine, m_StringMessage, oETCS::DF::CEVCStateMachine::Notify(), and oETCS::DF::STRING.
Member Data Documentation
| oETCS::DF::BOOL_INPUT_T oETCS::DF::CDMIOutput::m_bBoolMessage |
storage of a boolean message
Definition at line 1818 of file FunctionBlocks.h.
Referenced by Calculate().
| oETCS::DF::BOOL_INPUT_T oETCS::DF::CDMIOutput::m_bVisible |
storage of the visible flag input
Definition at line 1853 of file FunctionBlocks.h.
| oETCS::DF::DOUBLE_INPUT_T oETCS::DF::CDMIOutput::m_dDoubleMessage |
storage of a double message
Definition at line 1825 of file FunctionBlocks.h.
Referenced by Calculate().
| oETCS::DF::DOUBLE_ARRAY_INPUT_T oETCS::DF::CDMIOutput::m_DoubleArrayMessage |
storage of a double array message
Definition at line 1832 of file FunctionBlocks.h.
Referenced by Calculate(), and oETCS::DF::CDMIQWidget::UpdateSlot().
| const oETCS::DF::DATA_T oETCS::DF::CDMIOutput::m_eType |
| oETCS::DF::INT_INPUT_T oETCS::DF::CDMIOutput::m_iIntMessage |
storage of an integer message
Definition at line 1839 of file FunctionBlocks.h.
Referenced by Calculate().
| const ::std::string oETCS::DF::CDMIOutput::m_Label |
optional label
Definition at line 1860 of file FunctionBlocks.h.
|
inherited |
pointer to the all contenting EVC state machine
Definition at line 894 of file EVCStateMachine.h.
Referenced by oETCS::DF::CCondition::Calculate(), and Calculate().
| oETCS::DF::STRING_INPUT_T oETCS::DF::CDMIOutput::m_StringMessage |
storage of a string message
Definition at line 1846 of file FunctionBlocks.h.
Referenced by Calculate().
The documentation for this class was generated from the following files:
