oETCS::DF::CComBlockOut Class Reference

communication class for outgoing messages in a data flow More...

#include <FunctionBlocks.h>

Inheritance diagram for oETCS::DF::CComBlockOut:

Collaboration diagram for oETCS::DF::CComBlockOut:

Public Member Functions
virtual void	Calculate () throw (::oETCS::DF::Error::CException)
	pure virtual method for computing all outputs
	CComBlockOut (oETCS::DF::CEVCStateMachine *const pStateMachine, const ::std::vector< oETCS::DF::CBaliseDeviceOut * > &OutDevices) throw ()
	general constructor
virtual	~CComBlockOut () throw ()
	destructor

Public Attributes
oETCS::DF::BOOL_INPUT_T	m_bSendTelegram
	storage of the flag for sending a telegram
oETCS::DF::CEVCStateMachine *const	m_pStateMachine
	pointer to the all contenting EVC state machine

Private Attributes
const ::std::vector < oETCS::DF::CBaliseDeviceOut * >	m_OutDevices
	vector with pointers to all communication out devices in this com block

Detailed Description

communication class for outgoing messages in a data flow

Definition at line 1581 of file FunctionBlocks.h.

Constructor & Destructor Documentation

oETCS::DF::CComBlockOut::CComBlockOut ( oETCS::DF::CEVCStateMachine *const  pStateMachine, const ::std::vector< oETCS::DF::CBaliseDeviceOut * > &  OutDevices  ) throw ()

explicit

general constructor

Parameters

[in]	pStateMachine	pointer to the parent EVC state machine object
[in]	OutDevices	vector with pointers to all out devices (takes over posession)

Definition at line 1558 of file FunctionBlocks.cpp.

oETCS::DF::CComBlockOut::~CComBlockOut ( ) throw ()

virtual

destructor

Definition at line 1572 of file FunctionBlocks.cpp.

References m_OutDevices.

Member Function Documentation

void oETCS::DF::CComBlockOut::Calculate ( ) throw (::oETCS::DF::Error::CException)

virtual

pure virtual method for computing all outputs

Remarks

must me implemented by any inheriting class

Implements oETCS::DF::CFunctionBlock.

Definition at line 1593 of file FunctionBlocks.cpp.

References m_bSendTelegram, and m_OutDevices.

Member Data Documentation

oETCS::DF::BOOL_INPUT_T oETCS::DF::CComBlockOut::m_bSendTelegram

storage of the flag for sending a telegram

Definition at line 1613 of file FunctionBlocks.h.

Referenced by Calculate().

const ::std::vector< oETCS::DF::CBaliseDeviceOut* > oETCS::DF::CComBlockOut::m_OutDevices

private

vector with pointers to all communication out devices in this com block

Definition at line 1622 of file FunctionBlocks.h.

Referenced by Calculate(), and ~CComBlockOut().

oETCS::DF::CEVCStateMachine* const oETCS::DF::CFunctionBlock::m_pStateMachine

inherited

pointer to the all contenting EVC state machine

Definition at line 894 of file EVCStateMachine.h.

Referenced by oETCS::DF::CCondition::Calculate(), and oETCS::DF::CDMIOutput::Calculate().

---

The documentation for this class was generated from the following files:

• FunctionBlocks.h
• FunctionBlocks.cpp
