empty/stub class for the ::oETCS::DF::ABaliseDeviceIn adapter More...

Inheritance diagram for oETCS::DF::PS::CBaliseDeviceIn:

Collaboration diagram for oETCS::DF::PS::CBaliseDeviceIn:

Signals
void	Error (const ::QString &ErrorMessage)
	signal for sending an error
void	NewTelegram (const QByteArray &Bytes, int iBits)
	signal for sending a new telegram

Public Member Functions
	CBaliseDeviceIn (::QObject *const pParent=nullptr) throw ()
	default/general constructor
virtual	~CBaliseDeviceIn () throw ()
	destructor

Private Attributes
::std::list< ::QBitArray >	m_Telegrams
	list of telegrams to be send (by polling/calling)

Detailed Description

empty/stub class for the ::oETCS::DF::ABaliseDeviceIn adapter

This class is meant to be extened for any certain in Balise device implementation.

Definition at line 52 of file AdaptorStubsMOC.h.

Constructor & Destructor Documentation

oETCS::DF::PS::CBaliseDeviceIn::CBaliseDeviceIn ( ::QObject *const pParent = nullptr ) throw ()

default/general constructor

Parameters

[in] pParent optional pointer to a parent object, must be used, if stub is exetened by inheritance

Definition at line 38 of file AdaptorStubsMOC.cpp.

oETCS::DF::PS::CBaliseDeviceIn::~CBaliseDeviceIn ( ) throw ()

virtual

destructor

Definition at line 50 of file AdaptorStubsMOC.cpp.

void oETCS::DF::CBaliseDeviceIn::Error ( const ::QString & ErrorMessage )

signal

signal for sending an error

This signal should be emitted in the case that an error in the HW ocurres.

Parameters

[in] ErrorMessage textual description of the error

void oETCS::DF::PS::CBaliseDeviceIn::NewTelegram	(	const QByteArray &	Bytes,
		int	iBits
	)

signal

signal for sending a new telegram

This signal should be emitted, if a new telegram was received by the HW.

Parameters

[in]	Bytes	array of bytes of the new telegram
[in]	iBits	number of bits only used from the beginning in the byte array

::std::list< ::QBitArray > oETCS::DF::PS::CBaliseDeviceIn::m_Telegrams

private

list of telegrams to be send (by polling/calling)

Definition at line 103 of file AdaptorStubsMOC.h.

The documentation for this class was generated from the following files:
